PTFE成形チューブ
PTFE成形チューブは化学的に不活性で安全であり、-400°Fから+550°Fまでの広い使用温度範囲を備えています。さらに、成形PTFEチューブは摩擦係数が低く、優れた耐熱性と高い絶縁破壊電圧を備えています。
これ PTFEチューブの種類 圧縮成形プロセスによって製造されます。PTFEパイプは融点と分子量が高いため、圧縮成形に適しています。
中国のPTFE成形チューブ専門メーカー
PTFEチューブの圧縮成形には、 ポリテトラフルオロエチレン粉末 常温下で圧縮力に耐えられるよう成形されたPTFEチューブを製造し、その後焼結してチューブを製造します。
PTFEチューブの成形はコスト効率に優れ、廃棄物の削減にもつながります。PTFE成形チューブの厚さは2mmから6mmまで様々ですが、圧縮成形されたPTFEチューブの直径は最大300mmにもなります。
圧縮成形チューブは、あらゆる用途に適した多目的プロセスです。 ポリテトラフルオロエチレングレードPTFEチューブは、バージングレード、改質グレード、機械グレード、または 充填PTFE素材
Key Features of PTFE Molded Tube

腐食耐性があり、腐食性物質やほとんどの化学媒体(pH 0 ~ 14)に耐えることができます。

常温では良好な圧縮性およびクリープ耐性を示しますが、高温下では軟化することがあり、低応力の用途に適しています。

摩擦係数 (COF) は 0.04 と低く、自己潤滑性を備えた滑らかな表面により外部潤滑剤が不要です。
動作範囲は、持続的なサービスでは -200°C ~ +260°C で、短期的な露出許容範囲は 300°C までです。
PTFE成形チューブの用途
成形されたPTFEチューブは最終製品として使用することも、さらに加工して他の部品を製造することもできます。一般的な用途としては、以下のようなものがあります。
- LSR 射出成形機、ソフトゲルカプセル化機などの機械内のチューブ。
- スパゲッティ チューブ – 主に医療、自動車、化学産業で使用される柔軟で薄い PTFE 成形チューブです。
- PTFE ホース – 壁が厚いため、高圧用途に適しています。
- PTFE スリーブ – 一般的な用途には、リング、荷重ベアリング、シール、ガスケットなどがあります。

Production Process for PTFE Tubes As Following Steps

Select PTFE resin that meets purity requirements. Pre-treat the resin to remove any surface impurities, ensuring the final product’s purity and appearance aren’t affected.

Choose a mold size that matches customer specifications. Clean the mold surface thoroughly and apply a specialized release agent to prevent sticking.

At room temperature, fill the mold with the pre-treated PTFE powder. Use a hydraulic press to compress the powder, forming a dense, tube-shaped preform.

Remove the cold-pressed preform from the mold and place it in a sintering oven. Under high heat, the PTFE particles melt and fuse together, creating a solid, continuous structure.

Cut the sintered tubes according to the required specifications. Finally, perform quality inspection to ensure the product meets all standards.
- 物理的特性
- 仕様書
プロパティ | ユニット | 結果 |
見かけ密度 | g/m³ | 2.10~2.30 |
引張強度(分) | MPa | 15.0 |
破断伸び(分) | % | 150 |
絶縁耐力(分) | KV/mm | 10 |
φ30*10*100 | φ72*33*150 |
φ30*20*100 | Φ67*38*125 |
φ35*15*100 | φ75*25*150 |
φ40*15*150 | φ75*30*150 |
φ40*20*100 | φ75*35*150 |
φ40*25*100 | φ75*40*150 |
φ40*30*100 | φ75*45*150 |
φ45*25*100 | φ75*55*100 |
φ45*28*72 | φ80*45*150 |
φ45*30*100 | φ80*40*150 |
φ47*24*40 | φ80*20*100 |
φ50*15*200 | φ80*50*150 |
φ200*150*300 | φ690*588*250 |
φ200*165*150 | φ690*590*230 |
φ200*170*150~300 | φ690*640*100–80 |
φ200*180*150 | φ690*625*120 |
φ200*60*150 | Φ700*480*30 |
φ200*65*100 | φ710*480*100 |
φ200*75*100 | Φ710*500*100 |
φ200*80*100 | φ710*580*170 |
φ200*90*100 | φ710*595*170 |
φ205*140*150 | φ710*600*90 |
φ205*150*200 | φ710*640*150 |
φ205*58*320 | φ730*550*100 |
φ210*100*100-210 | Φ730*588*250 |
φ660*625*120 | φ1162*997*153 |
Φ2180*2100*40 | φ1230*1140*80 |
Φ2080*2000*40 | φ1230*997*100 |
Φ1880*1800*40 | Φ1390*1290*120 |
Φ1525*1445*80 | φ1450*1310*45 |
